Trion Air Boss T5200 Electronic Air Cleaner

Search Results for

    Unit Assembly

    Diagram

    Unit Assembly
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13

    Unit Assembly

    1. 1
      Zinc Hinge
      Zinc Hinge
      SKU: TRN146442001
      $52.47
    2. 2
      Aluminum Filter
      Aluminum Filter
      SKU: TRN224451006
      $114.68
    3. 3
      Collector Cell
      Collector Cell
      SKU: TRN450568001
    4. 4
      Adhesive Back Gasket
      Adhesive Back Gasket
      SKU: TRN126737031
    5. 5
      Adhesive Back Gasket
      Adhesive Back Gasket
      SKU: TRN126737034
    6. 6
      Turn Fastener
      Turn Fastener
      SKU: TRN334562005
      $87.72
    7. 7
      Cell Door Assembly
      Cell Door Assembly
      SKU: TRN350378001
    8. 8
      Blower Access Cover
      Blower Access Cover
      SKU: TRN338423001
    9. 9
      Blower Assembly 2HP
      Blower Assembly 2HP
      SKU: TRN438449001
    10. 9
      Blower Assembly 2HP
      Blower Assembly 2HP
      SKU: TRN438449002
    11. 9
      Blower Assembly 3HP
      Blower Assembly 3HP
      SKU: TRN438449003
    12. 10
      Gasket
      Gasket
      SKU: TRN224779006
      $5.59
    13. 11
      Exhaust End Cover
      Exhaust End Cover
      SKU: TRN338429001
    14. 12
      Grill Assembly
      Grill Assembly
      SKU: TRN242372002
    15. 13
      Cap Plug
      Cap Plug
      SKU: TRN247962002
      $1.00
    Blower Motor 2/3 HP Assembly

    Diagram

    Blower Motor 2/3 HP Assembly
    2
    3
    4
    5
    6
    7
    8
    9
    10
    10
    11
    12
    14
    15
    16
    17
    18
    19
    20
    21

    Blower Motor 2/3 HP Assembly

    1. 2
      Housing
      Housing
      SKU: TRN335025101
    2. 3
      Mounting Angle Foot LH
      Mounting Angle Foot LH
      SKU: TRN335025107
    3. 4
      Mounting Angle Foot RH
      Mounting Angle Foot RH
      SKU: TRN335025108
    4. 5
      Isolator
      Isolator
      SKU: TRN335025109
    5. 6
      Bearing Bracket Segment
      Bearing Bracket Segment
      SKU: TRN335025102
    6. 7
      Bearing
      Bearing
      SKU: TRN335025105
    7. 8
      Shaft
      Shaft
      SKU: TRN335025106
    8. 9
      Blower Wheel
      Blower Wheel
      SKU: TRN335025104
    9. 10
      Motor Mounting Bracket
      Motor Mounting Bracket
      SKU: TRN335025111
    10. 11
      Machine Screw
      Machine Screw
      SKU: TRN220008260
      $0.94
    11. 12
      Adjusting Screw Bracket
      Adjusting Screw Bracket
      SKU: TRN137591001
      $29.75
    12. 14
      Flanged Locknut
      Flanged Locknut
      SKU: TRN90000000301
      $0.58
    13. 15
      Hex Screw
      Hex Screw
      SKU: TRN220008253
      $0.29
    14. 16
      Motor
      Motor
      SKU: TRN124885008
      $2,753.93
    15. 16
      Motor
      Motor
      SKU: TRN124885011
    16. 16
      Motor
      Motor
      SKU: TRN124885010
    17. 17
      Sheave Pulley 3HP
      Sheave Pulley 3HP
      SKU: TRN125699020
      $231.61
    18. 17
      Sheave Pulley 2HP
      Sheave Pulley 2HP
      SKU: TRN125699019
    19. 18
      Gasket Material
      Gasket Material
      SKU: TRN224779028
      $10.26
    20. 19
      Flange
      Flange
      SKU: TRN338464001
    21. 20
      Blower Sheave or Pulley 3HP
      $172.97
    22. 20
      Blower Sheave or Pulley 2HP
    23. 21
      Belt 2HP
      Belt 2HP
      SKU: TRN234887004
    24. 21
      Belt 3HP
      Belt 3HP
      SKU: TRN234887038

    Blower Motor 2/3 HP Assembly Not In Diagram

    1. Not Shown
      Blower Assembly 3HP
      Blower Assembly 3HP
      SKU: TRN340599001
      $1,728.29
    2. Not Shown
      Blower Assembly 2HP
      Blower Assembly 2HP
      SKU: TRN335025001
    Blower Motor 5 HP Assembly

    Diagram

    Blower Motor 5 HP Assembly
    1
    1
    2
    4
    5
    6
    7
    7
    8
    9
    10
    10
    11

    Blower Motor 5 HP Assembly

    1. 1
      Modified Blower
      Modified Blower
      SKU: TRN359344001
    2. 2
      Motor Mount
      Motor Mount
      SKU: TRN259337001
    3. 4
      Motor Sheave
      Motor Sheave
      SKU: TRN125699014
    4. 4
      Variable Pitch Sheave
      Variable Pitch Sheave
      SKU: TRN125699021
    5. 5
      Blower Sheave
      Blower Sheave
      SKU: TRN124053041
    6. 5
      Blower Sheave
      Blower Sheave
      SKU: TRN124053062
    7. 6
      A Belt
      A Belt
      SKU: TRN234887008
    8. 6
      B Belt
      B Belt
      SKU: TRN323215060
    9. 7
      Mounting Bracket
      Mounting Bracket
      SKU: TRN359330001
    10. 8
      Mounting Bracket
      Mounting Bracket
      SKU: TRN359330002
    11. 9
      Threaded Rod
      Threaded Rod
      SKU: TRN159339001
    12. 10
      Conduit
      Conduit
      SKU: TRN121707002
    13. 11
      Blower Gasket Flange
      Blower Gasket Flange
      SKU: TRN256232001

    Blower Motor 5 HP Assembly Not In Diagram

    1. Not Shown
      Motor 5HP
      Motor 5HP
      SKU: TRN140367001
    2. Not Shown
      Motor 5HP
      Motor 5HP
      SKU: TRN345515132
    Collector Cell

    Diagram

    Collector Cell
    1
    2
    3
    4
    5
    6
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    15
    16
    17
    18
    18
    19
    20

    Collector Cell

    1. 1
      End Plate LH
      End Plate LH
      SKU: TRN450551001
    2. 2
      End Plate RH
      End Plate RH
      SKU: TRN450551002
    3. 3
      Ground Plate
      Ground Plate
      SKU: TRN226555001
      $16.73
    4. 4
      Spacer
      Spacer
      SKU: TRN220107070
      $5.47
    5. 5
      Cell Brace
      Cell Brace
      SKU: TRN247924002
    6. 6
      Insulator
      Insulator
      SKU: TRN352212002
      $82.14
    7. 7
      Handle
      Handle
      SKU: TRN124537001
    8. 8
      Rivet
      Rivet
      SKU: TRN220976044
    9. 9
      Contact Assembly
      Contact Assembly
      SKU: TRN147704002
      $45.94
    10. 10
      Spacer
      Spacer
      SKU: TRN220107111
    11. 11
      Spacer
      Spacer
      SKU: TRN220107112
      $72.98
    12. 12
      Ionizer Ground Plate
      Ionizer Ground Plate
      SKU: TRN247782001
    13. 13
      Spiked Ionizer Blade
      Spiked Ionizer Blade
      SKU: TRN347892001
    14. 14
      Brace
      Brace
      SKU: TRN250567001
    15. 15
      Tie Rod
      Tie Rod
      SKU: TRN233137031
    16. 16
      Tie Rod
      Tie Rod
      SKU: TRN233137030
    17. 17
      Blower Rod
      Blower Rod
      SKU: TRN233137015
    18. 18
      Ionizer Ground Spacer
      Ionizer Ground Spacer
      SKU: TRN220107109
    19. 19
      Spike Spacer
      Spike Spacer
      SKU: TRN220107110
    20. 20
      Ionizer Ground Spacer
      Ionizer Ground Spacer
      SKU: TRN121993006
    Enclosure Assembly

    Diagram

    Enclosure Assembly
    1
    2
    3
    4
    5
    6
    6
    7
    8
    9

    Enclosure Assembly

    1. 1
      LED
      LED
      SKU: TRN241101014
      $91.30
    2. 2
      Off Switch
      Off Switch
      SKU: TRN243765001
      $46.74
    3. 3
      Terminal Block
      Terminal Block
      SKU: TRN221442004
    4. 4
      Terminal Block Marker Strip
    5. 5
      Contactor
      Contactor
      SKU: TRN263726001
    6. 6
      Circuit Board
      Circuit Board
      SKU: TRN347891026
    7. 7
      Transformer
      Transformer
      SKU: TRN248655005
      $394.62
    8. 7
      Transformer
      Transformer
      SKU: TRN248655004
      $575.97
    9. 7
      Transformer
      Transformer
      SKU: TRN248655007
    10. 8
      Component Box Welded
      Component Box Welded
      SKU: TRN450376001
    11. 9
      Overload Relay
      Overload Relay
      SKU: TRN243862008
    12. 9
      Overload Relay
      Overload Relay
      SKU: TRN243862009
    13. 9
      Overload Relay
      Overload Relay
      SKU: TRN243862010
    14. 9
      Overload Relay
      Overload Relay
      SKU: TRN243862012
