Trion FM1000E Air Cleaner

Search Results for

    Select a diagram to view its parts

    Parts

    Diagram

    Parts
    1
    2
    3
    4
    5
    6
    6A
    7
    8
    9
    10
    11
    12
    13
    14
    15
    15
    16
    16
    17
    18
    18
    19
    20
    27
    28
    29

    Parts

    1. 1
      Grill
      Grill
      SKU: TRN440549001
      $93.24
    2. 2
      After Filter
      After Filter
      SKU: TRN227833006
      $34.43
    3. 3
      Rotary Switch
      Rotary Switch
      SKU: TRN228276001
      $33.99
    4. 4
      Knob
      Knob
      SKU: TRN139999001
      $23.38
    5. 5
      Prefilter
      Prefilter
      SKU: TRN240550001
      $62.17
    6. 6
      Screw
      Screw
      SKU: TRN120034506
      $4.86
    7. 6A
      Bolt Retainer
      Bolt Retainer
      SKU: TRN244225004
      $0.72
    8. 7
      Access Door
      Access Door
      SKU: TRN440541001
      $259.50
    9. 8
      Collector Cell
      Collector Cell
      SKU: TRN441729103
    10. 9
      Filter Media
      Filter Media
      SKU: TRN340553001
      $242.43
    11. 10
      Fan Blade
      Fan Blade
      SKU: TRN140551001
      $98.90
    12. 11
      Collector Cell Latch
      Collector Cell Latch
      SKU: TRN240537001
    13. 12
      Motor
      Motor
      SKU: TRN340623001
      $553.75
    14. 13
      Board Assembly
      Board Assembly
      SKU: TRN234458006
      $14.76
    15. 14
      Circuit Board
      Circuit Board
      SKU: TRN341677601F
    16. 15
      Red Indicator Lamp
      Red Indicator Lamp
      SKU: TRN134516013
      $24.91
    17. 16
      Green Indicator Lamp
      Green Indicator Lamp
      SKU: TRN134516007
      $28.41
    18. 17
      Name Plate
      Name Plate
      SKU: TRN240060001
    19. 18
      Capacitor
      Capacitor
      SKU: TRN129040003
      $50.26
    20. 19
      Push Button
      Push Button
      SKU: TRN132122001
      $3.62
    21. 20
      Pole Switch
      Pole Switch
      SKU: TRN132311001
      $54.86
    22. 27
      Positioning Bracket
      Positioning Bracket
      SKU: TRN340659001
    23. 28
      Positioning Bracket
      Positioning Bracket
      SKU: TRN340660001
    24. 29
      Transformer
      Transformer
      SKU: TRN240636001
      $112.42

    Parts Not In Diagram

    1. Not Shown
      Repair & Diagnosis
      Repair & Diagnosis
      SKU: DIAGNOSTIC-TRN
      $57.53
    2. Not Shown
      Washer
      Washer
      SKU: TRN120456001
      $5.15
    3. Not Shown
      Ionizing Wire
      Ionizing Wire
      SKU: TRN220111029
      $10.80
    4. Not Shown
      Control Switch Label
      Control Switch Label
      SKU: TRN244223001
    5. Not Shown
      Discharge Kit-less Duct
      Discharge Kit-less Duct
      SKU: TRN440734001
    6. Not Shown
      Plenum Inlet Adapter
      Plenum Inlet Adapter
      SKU: TRN340564001
    7. Not Shown
      Cabinet Outlet Adapter
      Cabinet Outlet Adapter
      SKU: TRN440559001
    8. Not Shown
      Outlet Plenum
      Outlet Plenum
      SKU: TRN340546001
